Leonardo Helicopters AW119
Overview
The Leonardo AW119 Koala is a single-engine turbine helicopter for training, utility, EMS, and law-enforcement missions. It shares design heritage with the AW109 family but uses one engine for lower acquisition and operating cost. A spacious cabin and high useful load support diverse civil roles. Training schools and public agencies are core customers.
Quick Facts
Range
535 nm
Cruise Speed
139 kt
Max Speed
152 kt
Specifications
| ICAO Type Code | A119 |
|---|---|
| Military Designation | TH-73A |
| Length | 42 ft 11 in |
| Wingspan / Rotor Diameter | 35 ft 7 in rotor diameter |
| Height | 11 ft 6 in |
| Empty Weight | 3300 lb |
| Max Takeoff Weight | 6283 lb |
| Cruise Speed | 139 kt |
| Max Speed | 152 kt |
| Range | 535 nm |
| Service Ceiling | 15000 ft |
| Engine Manufacturer | Pratt & Whitney Canada |
| Engine Model | PT6B-37A |
| Engine Count | 2 |
Data verification status: Partially Verified
Source: Leonardo — AW119Kx
