Robinson Helicopter R44
Overview
The Robinson R44 is a four-seat light piston helicopter that became one of the world's most widely flown civil rotorcraft. Derived from the two-seat R22 design philosophy—simple systems, low operating cost, and straightforward maintenance—the R44 serves training, touring, electronic news gathering, and light utility roles. Raven II and later configurations improved altitude and payload performance. Operators value its relatively modest acquisition and hourly costs compared with light turbines. As with all light helicopters, safe operation depends on disciplined training and adherence to height-velocity and density-altitude limits. The R44 remains a backbone type in many flight schools and private fleets.
Quick Facts
Specifications
| ICAO Type Code | R44 |
|---|---|
| Length | 38 ft 3 in |
| Wingspan / Rotor Diameter | 33 ft rotor diameter |
| Height | 10 ft 9 in |
| Empty Weight | 1505 lb |
| Max Takeoff Weight | 2500 lb |
| Cruise Speed | 109 kt |
| Max Speed | 130 kt |
| Range | 350 nm |
| Service Ceiling | 14000 ft |
| Engine Manufacturer | Lycoming |
| Engine Model | O-540 / IO-540 series |
| Engine Count | 1 |
Data verification status: Partially Verified
Source: ICAO Aircraft Type Designators
